| Class | 150 | 300 | 400 | 600 | 900 | 1500 | 2500 |
| Diameter - A | 30 | 38 | 38 | 38 | 38 | 38 | 43 |
| Diameter - D | 90 | 95 | 95 | 95 | 120 | 120 | 135 |
| Thickness - B | 9.6 | 12.7 | 14.3 | 14.3 | 22.3 | 22.3 | 30.2 |
| 11.2 | 14.3 | 20.7 | 20.7 | 28.7 | 28.7 | 36.6 | |
| Diameter - G | 35.1 | 35.1 | 35.1 | 35.1 | 35.1 | 35.1 | 35.1 |
| Diameter - K | 60.3 | 66.7 | 66.7 | 66.7 | 82.6 | 82.6 | 88.9 |
| Height - H | 46 | 51 | 52 | 52 | 60 | 60 | 73 |
| 47.6 | 52.6 | 58.4 | 58.4 | 66.4 | 66.4 | 79.4 | |
| Bolt Holes | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Diameter - L | 15.9 | 15.9 | 15.9 | 15.9 | 22.2 | 22.2 | 22.2 |
| Stud Bolts Diameter x Length | |||||||
| Diameter (in) | 1/2 | 1/2 | 1/2 | 1/2 | 3/4 | 3/4 | 3/4 |
| Length (mm) | 55 | 65 | 75 | 75 | 110 | 110 | 120 |
| Outside Diameter = 24 = 1.6 mm | > 24 = ± 3.2 mm |
Inside Diameter = 10 = ± 0.8 mm | 12 thru 18 = 1.6 mm | = 20 = + 3.2 mm / - 1.6 mm |
| Diameter of Contact Face 1.6 mm Raised Face = ± 0.8 mm 6.35 mm Raised Face, Tongue & Groove / Male-Female = ± 0.4 mm |
Diameter of Hub at Base = 24 = 1.6 mm | > 24 = ± 3.2 mm |
| Diameter of Hub at Point of Welding = 5 = + 2.4 mm / - 0.8 mm | = 6 = + 4.0 mm / - 0.8 mm |
Drilling Bolt Circle = 1.6 mm | Bolt Hole Spacing = ± 0.8 mm Eccentricity of Bolt Circle with Respect to Facing = 2½ = 0.8 mm max. | = 3 = 1.6 mm max |
| Thickness = 18 = + 3.2 mm / - 0 | = 20 = + 4.8 mm / - 0 |
Length thru Hub = 10 = 1.6 mm | = 12 = ± 3.2 mm |
