Ascent Engineering Company can't keep away from being India's remarkable producer, supplier and exporter of IBR Approved Products. Our ability let us to come up by systems for a first rate set of such things in the business. With different sorts like IBR Weld Neck (WNRF), IBR Socket Weld (SWRF), IBR Slip-On (SORF), IBR Blind (BLRF), IBR Lap Joint, IBR Screwed (Threaded), IBR Long Weld Neck, IBR Reducing, IBR Ring Joint, IBR Orifice, and IBR Girth Flange, we additionally offer particular edge, for instance, Tee, Cross, Union, 45 Deg Elbow, 90 Deg Elbow, Half Coupling, Full Coupling, Boss, Plug and some more.
IBR is Indian Boiler Regulations, which was made in fifteenth September 1950 in exercise of the powers appeared by parcel 28 and 29 of the Indian Boilers Act. The Indian Boilers Act was included in 1923, 23rd February to unite and change the law relating to steam boilers.
IBR Pipe :
Size : 1/2"NB TO 24"NB IN
Schedule : SCH20, SCH30, SCH40, STD, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless
Length : Single Random, Double Random & Cut Length.
End : Plain End, Beveled End, Treaded.
MATERIALS :
IBR Stainless Steel Pipes
ASTM 312 / 213 - TP 304 / 304L / 304H / 316 / 316L / 317 / 317L / 321 / 310 / 347
IBR Carbon Steel Pipe :
ASTM A 53, A106 Gr. B, API 5L GR.B, API 5L X 42.
IBR LTCS Pipe :
ASTM A333 Gr.6
IBR Alloy Steel Pipe :
ASTM / ASME A/SA 335 Gr. P 1, P 5, P 9, P 11, P 12, P 22, P 91
Schedule : SCH20, SCH30, SCH40, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless
Form : Elbow, Tee, Reducer, Cap, Stubend, Bends, Nipple etc.
Materials :
IBR Carbon Steel Fitting
ASTM A 234 WPB
IBR LTCS Fittings :
A420WPL6
IBR Alloy Steel Fitting :
ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
IBR Flanges :
Size : 1/2"NB TO 60"NB IN
Class : 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.
Type :
• IBR Weld Neck (WNRF)
• IBR Â Socket Weld (SWRF)
• IBR Â Slip On (SORF)
• IBR Blind (BLRF)
• IBR Lap Joint
• IBR Screwed (Threaded)
• IBR Long Weld Neck
• IBR Reducing
• IBR Ring Joint
• IBR Orifice
• IBR Girth Flange
SPECIFICATIONS AS PER THE INTERNATIONAL STANDARD ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, NA
Materials :
IBR Alloy Steel Flanges
ASTM SA 182 F1/F5/F9/F11/F22/F91
IBR Carbon Steel Flanges :
ASTMA 105 Gr. F42/46/52/56/60/65/70
IBR LTCS Flanges :
A350 LF2/A350 LF3
IBR Forged Fittings :
Size : 1/4"NB TO 4"NB IN
Class : 3000 LBS, 6000 LBS, 9000 LBS
Type :
Socket Weld (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT
Form :
• Tee
• Cross
• Union
• 45 Deg Elbow
• 90 Deg Elbow
• Half Coupling
• Full Coupling
• Boss
• Plug
• Cap
• Bushing
• Hex Nipple
• Swage Nipple
• Customized Fittings
Materials :
IBR Alloy Steel Forged Fitting
ASTM / ASME A/SA 182 F1/F5/F9/F11/F22/F91
IBR Carbon Steel Forged Fitting :
ASTMA 105/A694/ Gr. F42/46/52/56/60/65/70
IBR LTCS Forged Fittings :
A350 LF3/A350 LF2
IBR Outlets :
Size : 1/4"NB TO 24"NB IN
Class :
3000 LBS, 6000 LBS, 9000 LBS & Required Schedule
Type :
Socket Weld (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT
Outlet’s :
• Weldolet
• Sockolet
• Elbowlet
• Thredolet
• Nipolet
• Letrolet
• Swepolet
Material :
IBR Alloy Steel Outlet
ASTM / ASME A/SA 182 F1/F5/F9/F11/F22/F91
IBR Carbon Steel Outlet :
ASTMA 105
IBR LTCS Outlet :
A350 LF2
IBR Pipe :
Size : 1/2"NB TO 24"NB IN
Schedule :
SCH20, SCH30, SCH40, STD, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type :
Seamless
Length :
Single Random, Double Random & Cut Length.
End :
Plain End, Beveled End, Treaded.
Materials :
IBR Carbon Steel Pipe
ASTM A 53, A106 Gr. B, API 5L GR.B, API 5L X 42.
IBR LTCS Pipe :
ASTM A333 Gr.6
IBR Alloy Steel Pipe :
ASTM / ASME A/SA 335 Gr. P 1, P 5, P 9, P 11, P 12, P 22, P 91
IBR Tube :
Size : 6.35mm OD upto 254mm OD in 0.6 to 20mmthk.
Schedule : In Various SWG & BWG
Type : Seamless / ERW / Welded
Length : Single Random, Double Random & Required Length.
End : Plain End, Beveled End, Treaded.
Other :
Boiler Tube
IBR Tube
Materials :
IBR Carbon Steel Tube
ASTM A 179 / A 210 Gr. A / BS 3059 Gr. 360 & 440.
IBR Alloy Steel Tube :
ASTM / ASME A/SA 213 Gr. T 1, T 5, T 9, T 11, T 12, T 22, T 91
IBR Bars :
IBR Alloy Steel Bar
ASTM SA 182 F1/F5/F9/F11/F22/F91
IBR Carbon Steel Bar :
ASTMA 105
IBR LTCS Bar :
A350 LF2/A350 LF3
Test Certificate :
IBR FORM III C, FORM III A, III D Test Certificate
