Flanges - Blind Flanges

Class	150	300	400	600	900	1500	2500
Diameter - A	30	38	38	38	38	38	43
Diameter - D	90	95	95	95	120	120	135
Thickness - B	9.6	12.7	14.3	14.3	22.3	22.3	30.2
Thickness - B	11.2	14.3	20.7	20.7	28.7	28.7	36.6
Diameter - G	35.1	35.1	35.1	35.1	35.1	35.1	35.1
Diameter - K	60.3	66.7	66.7	66.7	82.6	82.6	88.9
Height - H	14	21	22	22	32	32	40
Height - H	15.6	22.6	28.4	28.4	38.4	38.4	46.4
Bolt Holes	4	4	4	4	4	4	4
Diameter - L	15.9	15.9	15.9	15.9	22.2	22.2	22.2
Stud Bolts Diameter x Length
Diameter (in)	1/2	1/2	1/2	1/2	3/4	3/4	3/4
Length (mm)	55	65	75	75	110	110	120

Dimensional Tolerances of Threaded Flanges ASME B16.5

Outside Diameter = 24 = 1.6 mm \| > 24 = ± 3.2 mm	Inside Diameter Within Limits on Boring Gauge
Diameter of Contact Face 1.6 mm Raised Face = ± 0.8 mm 6.35 mm Raised Face, Tongue & Groove / Male-Female = ± 0.4 mm	Drilling Bolt Circle = 1.6 mm \| Bolt Hole Spacing = ± 0.8 mm Eccentricity of Bolt Circle with Respect to Facing = 2½ = 0.8 mm max. \| = 3 = 1.6 mm max.
Outside Diameter of Hub = 12 = + 2.4 mm / - 1.6 mm \| = 14 = ± 3.2 mm	Diameter of Counterbore Same as forInside Diameter
Thickness = 18 = + 3.2 mm / - 0 \| = 20 = + 4.8 mm / - 0	Length thru Hub = 18 = + 3.2 mm / - 0.8 mm \| = 20 = + 4.8 mm / - 1.6 mm

Notes:

1. Dimensions are in millimeters unless otherwise indicated.
2. The length of the stud bolt does not include the height of the chamfers (points).
